330100-50-05 | Bently Nevada | 3300 Proximitor Sensor
Bently Nevada 330100-50-05 3300 Proximitor Sensor
The Bently Nevada 330100-50-05, also cataloged as the 330100 Proximitor Sensor, operates as a dedicated hardware component for eddy-current probe signal conditioning and shaft displacement measurement within Bently Nevada 3300 proximity transducer systems. The sensor is configured for a 5.0 m system length and converts probe signal variations into calibrated outputs used for shaft position, vibration, and gap monitoring functions.
Suffix Breakdown & Model Matrix
The ordering code 330100-50-05 identifies a specific configuration within the Bently Nevada 3300 Proximitor Sensor family.
- 330100 designates the 3300 Proximitor Sensor series.
- 50 specifies a total transducer system length of 5.0 m (16.4 ft).
- 05 indicates the Multiple Approvals configuration option.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 330100-50-05 |
| Brand | Bently Nevada |
| Product Type | 3300 Proximitor Sensor |
| Total Length Option | 5.0 m (16.4 ft) |
| Agency Approval Option | Multiple Approvals |
| Sensor Housing Material | A383 Aluminum |
| Application | Eddy current proximity transducer systems |
| Measured Variables | Shaft vibration, shaft position, gap, eccentricity |
| Operating Temp | -51 deg C to 100 deg C |
| Storage Temp | -51 deg C to 100 deg C |
| Shipping Weight | 1.5 kg |
| Dimensions | Not specified in supplied data |
| Weight | Not specified in supplied data |
| Power Consumption | Not specified in supplied data |
| Origin | Not specified in supplied data |
Gap Voltage Validation and Transducer Calibration
The 330100-50-05 functions as the signal-conditioning component within a proximity transducer system consisting of a proximity probe, extension cable, and Proximitor sensor. System accuracy depends on calibration matching between all transducer components and the specified total system length.
For machinery monitoring applications, gap voltage validation is commonly performed during installation and maintenance activities. A static gap voltage near -10 VDC is frequently used as a reference condition for confirming that the probe operates within its calibrated measurement range. Proper gap adjustment supports linear response characteristics for shaft displacement and vibration measurements.
The A383 aluminum housing provides mechanical protection for the internal signal-conditioning circuitry while supporting installation in industrial machinery monitoring environments.
Frequently Asked Questions
Q: Is the 330100-50-05 intended to operate without an associated proximity probe?
A: No. The Proximitor sensor is one element of a complete proximity transducer system and requires a compatible probe and cable assembly.
Q: Why is total system length important for this sensor configuration?
A: The specified 5.0 m system length forms part of the calibrated transducer loop and must match the associated probe system configuration.
Q: What is the purpose of gap voltage verification during commissioning?
A: Gap voltage verification confirms that the probe-target relationship is within the intended operating region for accurate shaft position and vibration monitoring.
Field Installation Guidelines
- Verify compatibility between the Proximitor sensor, extension cable, and proximity probe before installation.
- Install the sensor on a rigid mounting surface to minimize mechanical stress on field wiring.
- Route transducer cables separately from motor feeders, switchgear conductors, and VFD output cables.
- Maintain continuous shielding practices throughout the transducer circuit.
- Confirm transducer polarity and wiring termination before energizing the monitoring channel.
- Measure and document gap voltage values during commissioning and periodic maintenance inspections.
- Protect field wiring from excessive bending, vibration, and mechanical abrasion.
