1C31125G02 | Ovation | Digital Output Module

Description

The Emerson Ovation 1C31125G02 is a Digital Output (DO) Module designed for Ovation Distributed Control Systems. It delivers fast, reliable control signals to discrete field devices such as solenoid valves, relays, and motor starters, making it ideal for demanding industrial automation environments.

Specifications

• Model Number: 1C31125G02
• Product Type: Digital Output Module
• Output Channels: 8 independent channels
• Output Type: Transistor-based (MOSFET/IGBT)
• Load Voltage Range: 24V DC (±20%) standard, optional 110V DC/AC
• Max Load Current per Channel: 0.5A at 24V DC
• Total Module Current: ≤4A
• Response Time: ≤1 ms
• Protection Features: Short-circuit, overload, and open-circuit protection
• Isolation Voltage: ≥1500V AC between channels
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Mounting: Ovation backplane slot
• Dimensions: Approx. 160 mm × 100 mm × 30 mm
• Weight: Approx. 200 g

Features

• Multi-Channel Output: Supports 8 configurable digital outputs for flexible control
• Fast Switching: Real-time response suitable for emergency shutdown valves and fast-acting devices
• Pulse Output Mode: Optional support for stepper motors and timed triggers
• Redundancy Support: Compatible with Ovation hot-swappable architecture
• Self-Diagnostics: Monitors output status and alerts for faults like overload or short circuit
• EMI Resistance: Designed to operate in high electromagnetic environments
• LED Indicators: Visual status for power, communication, channel activity, and faults
• Robust Integration: Seamlessly connects with Ovation controllers via high-speed backplane bus
• Industrial Versatility: Suitable for power generation, petrochemical, metallurgy, and water treatment applications
