ABB 07KR264 GJV3072403R1 Basic Configuration Unit

Description

The ABB 07KR264 GJV3 0724 03R1 is a Basic Configuration Unit (BCU) designed for the ABB Compact H PLC family. It serves as the central processor in modular automation setups, supporting a wide range of I/O modules and communication interfaces for flexible deployment in process, machine, and building control systems.

Specifications

• Model: 07KR264
• Part Number: GJV3 0724 03R1
• CPU: 32-bit ARM Cortex-A5
• Program Memory: 480 kB
• Data Memory: 256 kB
• Operating Voltage: 24 V DC
• I/O Capacity: Up to 64 points
• Communication Interfaces:
  • CS31 system bus
  • RS-232C / RS-485 (COM1, COM2)
  • Optional Ethernet
• Mounting Options: DIN rail (TH35-15 or TH35-7.5) or screw-mounted
• Protection Class: IP20
• Operating Temperature: 0°C to +55°C
• Storage Temperature: –25°C to +75°C
• Dimensions: 150 mm × 200 mm × 60 mm
• Weight: Approx. 1.65 kg
• Country of Origin: Sweden
• Warranty: 12 months

Features

• Modular Architecture: Supports scalable automation with multiple I/O configurations
• High Performance: ARM-based processing for fast logic execution
• Flexible Communication: Integrates easily with legacy and modern networks
• Compact Design: Ideal for space-constrained control panels
• Reliable Operation: Built for continuous use in industrial environments
• Easy Installation: DIN rail or screw-mount options for quick deployment
