ABB 1MRK000008-LBr02 Front Display Panel

Description

The ABB 1MRK000008-LBr02 is a front display panel engineered for RET670 protection and control IEDs. It functions as a graphical HMI, enabling operators to monitor relay status, alarms, and system diagnostics in real time. With ANSI symbol support and Ethernet/serial connectivity, it enhances operational visibility and control in industrial and utility power systems.

Specifications

• Model: 1MRK000008-LBr02
• Display Type: Graphical LCD with ANSI symbols
• Screen Size: 3.8 inches
• Resolution: 320 × 240 pixels
• Frame Size: ¾ × 19 inches (standard rack format)
• Power Supply: 24 VDC
• Communication Ports: Ethernet (RJ45), RS-485 serial
• Software Version: SW Rev 2.21
• Operating Temperature: –10°C to +55°C
• Storage Temperature: –40°C to +85°C
• Weight: Approx. 1.2 kg
• Certifications: CE compliant, CEC E239475
• Origin: Sweden or USA (varies by distributor)
• Connectivity: Compatible with front connection cable 1MKC950001-2

Features

• Real-Time Monitoring: Displays relay status, alarms, and diagnostics
• Graphical Interface: ANSI symbol support for intuitive navigation
• Industrial-Grade Build: Designed for harsh environments and utility-grade systems
• Multi-Protocol Support: Ethernet and RS-485 for flexible integration
• User-Friendly Access: Front panel interface for quick data retrieval
• RET670 Compatibility: Seamless integration with ABB’s high-performance protection relays
• Fast Deployment: Plug-and-play design with extensive stock availability
• Global Compliance: CE-certified and built to ABB’s rigorous standards
