ABB 3BHE009681R0101 3BHB013085R0001 5SHY3545L0009 IGCT Module

Product Description

• Model: 3BHE009681R0101 (GVC750BE101 type SCR module)
• Type: Silicon Controlled Rectifier (SCR)
• Application: Industrial power control for high-power applications
• Alternate Model: 3BHB013085R0001 (IGCT module)

Specifications

• Nominal Voltage: 4500V
• Nominal Current: 3500A
• Peak Turn-On Gate Current: 1000A
• Peak Turn-Off Gate Current: 1000A
• Turn-On Time: 1.5μs
• Turn-Off Time: 1.5μs
• On-State Voltage Drop: 2.5V
• Off-State Leakage Current: 10mA
• Nominal Power: 750A
• Working Temperature: -40°C to +125°C

Features

• High Power Handling: Designed to manage high-power industrial applications efficiently.
• Fast Switching: Features fast turn-on and turn-off times, enabling quick response to system changes.
• Robust Design: Built to endure harsh industrial conditions and ensure long-term performance.
• Efficiency: The module offers a low on-state voltage drop and minimal leakage current, enhancing overall system efficiency.
