ABB 3BHE009681R0101 3BHBO13088R0001 5SHY3545L0010 IGCT Module

Description

These 3BHE009681R0101 3BHBO13088R0001 5SHY3545L0010 IGCT modules are used in high-voltage direct current (HVDC) transmission, variable frequency drives (VFDs), static var compensators (SVCs), and soft-start protection systems. They offer fast switching speeds, low losses, and high surge current capability, making them ideal for power electronics applications.

Specifications

• Nominal Voltage: 4500V
• Nominal Current: 3500A
• Peak Turn-On Gate Current: 1000A
• Peak Turn-Off Gate Current: 1000A
• Turn-On Time: 1.5μs
• Turn-Off Time: 1.5μs
• On-State Voltage Drop: 2.5V
• Off-State Leakage Current: 10mA
• Junction Temperature: 125°C
• Dimensions: 320mm x 200mm x 150mm
• Weight: 20kg

Features

• High Voltage & Current Ratings: Supports 4500V and 3500A, ensuring robust performance in industrial applications.
• Fast Switching Speeds: 1.5μs turn-on and turn-off times for efficient power conversion.
• Low Switching Losses: Reduces energy dissipation, improving system efficiency.
• Integrated Gate Driver: Enhances control and reliability.
• High Surge Current Capability: Handles transient overloads effectively
