ABB 88QB03 Bus Termination Module

General Information

• Product ID: 88QB03
• Type: Bus Termination Module
• Application: Ensures proper termination of the bus system to reduce signal reflection and interference, improving data quality in automation systems.

Specifications

• Voltage: 24V
• Current: 210 mA
• Dimensions: 26.0 cm x 25.4 cm x 2 cm
• Weight: 0.5 kg
• Power Supply: Dual 24V supply

Features

• Bus Termination: Provides correct termination for the bus system.
• Central Clock-Pulse Supply: Supplies the central clock pulse for the connected modules.
• Plug-In Jumper: Allows for easy configuration of termination resistors.
• Dual Voltage Supply: Ensures stable power supply for termination resistors and clock pulse circuitry.
