ABB DA501:S500 Digital Analog I/O Module
SKU: DA501
In stock
Description

 General Information:

  • Extended Product Type: DA501
  • Product ID: 1SAP450700R0001
  • ABB Type Designation: DA501
  • EAN: 4016779846332
  • Catalog Description: Digital/analog I/O module. 16 DI: 24V DC. 4 AI: U, I, RTD, DI. 2 AO: U, I. 8 configurable DI/DO: 24V DC 0.5A (DA501-XC)
  • Long Description: DA501-XC: S500 Digital/analog I/O module. 16 DI: 24V DC. 4 AI: U, I, RTD. 2 AO: U, I. 8 configurable DI/DO: 24V DC 0.5A. 1-wire. eXtreme Conditions
  • CN8: 85389091
  • Invoice Description: Digital/analog I/O module. 16 DI: 24V DC. 4 AI: U, I, RTD, DI. 2 AO: U, I. 8 configurable DI/DO: 24V DC 0.5A (DA501)
  • Made To Order: No
  • Minimum Order Quantity: 1 piece
  • Order Multiple: 1 piece
  • Selling Unit of Measure: piece

Dimensions:

  • Product Net Weight: 0.122 kg
  • Product Net Depth / Length: 62 mm
  • Product Net Height: 76 mm
  • Product Net Width: 67.5 mm
  • Gross Weight: 0.146 kg
  • Package Level 1 Depth / Length: 84 mm
  • Package Level 1 Height: 72 mm
  • Package Level 1 Width: 71 mm
  • Package Level 1 Units: 1 carton

Technical:

  • Function: 16 DI: 24V DC. 4 AI: U, I, RTD. 2 AO: U, I. 8 configurable DI/DO: 24V DC 0.5A
  • Analog Inputs: 4
  • Input Signal: U, I, RTD, DI
  • Analog Outputs: 2
  • Output Signal: U, I
  • Resolution:
    • Analog Input: 13 bit
    • Analog Output: 13 bit
  • Number of Digital Inputs: 16
  • Number of Digital Configurable I/Os: 8
  • Input Voltage Type: DC
  • Input Voltage (Uin): 24 V DC
  • Input Current: 5 mA
  • Maximum Input Voltage: 30 V
  • Delay Time (τ): 0.1 … 32 ms
  • Output: Transistor
  • Output Voltage Type: DC
  • Output Voltage (Uout): 24 V DC
  • Output Current: 0.5 A
  • Degree of Protection: IP20
  • Rated Voltage (Ur): 24 V DC
  • Supply Voltage: 20.4 … 28.8 V DC
  • Ambient Air Temperature:
    • Operation: -30...+70 °C
    • Storage: -40...+85 °C

Additional Information:

  • Product Main Type: DA501
  • Product Name: Distributed Automation I/Os

Classifications:

  • eClass: 27-24-22-02
  • ETIM 8: EC001421 - PLC analogue/digital I/O-module
  • UNSPSC: 32151705

Environmental:

  • SCIP: aa2fa273-d3d5-4236-947e-4b31bd09a9d7 (Germany)
  • WEEE B2C / B2B: Business To Business
  • WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
