ABB DC562 1SAP231900R0000 Digital Input/Output Module

Product Information

• Extended Product Type: DC562
• Product ID: 1SAP231900R0000
• ABB Type Designation: DC562
• EAN: 4016779927574
• Catalog Description: Digital input/output module. Transistor: 16DC: 0.5 A (DC562)
• Long Description:
  • S500-eCo Digital input/output module
  • 16 configurable DI/DO, 24 V DC, 0.5 A, 1-wire

Dimensions

• Net Weight: 0.15 kg
• Net Depth / Length: 75 mm
• Net Height: 135 mm
• Net Width: 34 mm

Certificates and Declarations

• Declaration of Conformity (CE): 3AXD10002007200
• REACH Date: 2024-12-06
• REACH Declaration: 3ADR980139
• REACH Information: Contains substances >0.1 mass %
• SCIP: bfeea254-2f62-465d-8fb2-666407f08264 (Germany)
• RoHS Date: 2013
• RoHS Declaration: 3AXD10002007200
• RoHS Information: Following EU Directive 2011/65/EU and Amendment 2015/863 (July 22, 2019)

Technical

• Function: 16 configurable DI/DO, 24 V DC, 0.5 A
• Number of Digital Configurable I/Os: 16
• Input Voltage Type: DC
• Input Current: 5 mA
• Maximum Input Voltage: 0…30 V
• Delay Time (τ): 8 ms
• Output Type: Transistor
• Output Voltage Type: DC
• Output Current: 0.5 A
• Maximum Output Voltage: 20.4…28.8 V
• Connection Type: Pluggable
• Degree of Protection: IP20
• Supply Voltage: 20.4…28.8 V DC

Environmental

• WEEE B2C / B2B: Business To Business
• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
