ABB DI562 1TNE968902R2102 Digital Input Module

General Information:

• Extended Product Type: DI562
• Product ID: 1TNE968902R2102
• ABB Type Designation: DI562
• EAN: 6943747170220
• Catalog Description: Digital input module. 16 DI sink/source: 24VDC (DI562)
• Long Description: DI562: S500-eCo Digital input module. 16 DI sink/source: 24VDC. 1-wire.
• Invoice Description: Digital input module. 16 DI sink/source: 24VDC (DI562)
• Minimum Order Quantity: 1 piece
• Order Multiple: 1 piece
• Selling Unit of Measure: piece

Dimensions:

• Product Net Weight: 0.116 kg
• Product Net Depth / Length: 135 mm
• Product Net Height: 74 mm
• Product Net Width: 34 mm

Technical Specifications:

• Function: 16 DI sink/source: 24VDC
• Number of Digital Inputs: 16
• Number of Digital Configurable I/Os: 0
• Input Voltage Type: AC/DC
• Input Current: 5 mA
• Maximum Input Voltage: 0 ... 30 V
• Delay Time (τ): 8 … 8 ms
• Connection Type: Pluggable
• Degree of Protection: IP20
• Ambient Air Temperature:
  • Operation: 0 ... +60 °C
  • Storage: -40 ... +70 °C

Classifications:

• eClass: 27-24-22-04
• ETIM 8: EC001419 - PLC digital I/O-module
• UNSPSC: 32151705

Environmental:

• SCIP: 2a5298d5-fdc0-42f2-82a6-f96a09eb394f China (CN)
• WEEE B2C / B2B: Business To Business
• WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)
