ABB DSPU/41/950 Digital Signal Processor

Features:

• High-Speed Processing: Equipped with a 200 MHz 32-bit fixed-point DSP core for rapid computational capabilities.
• Flexible Architecture: Designed to accommodate a wide range of industrial control and signal processing tasks.
• Powerful Instruction Set: Supports various data types and operations effectively.
• On-Chip Memory:
  • 256 KB of on-chip SRAM for code and data storage.
  • 1 MB of off-chip SRAM.
  • 2 MB of flash memory.
• Extensive Peripherals: Includes comprehensive peripherals such as timers, counters, serial interfaces, and A/D converters.
• Software Support: Backed by a suite of software tools including compilers, assemblers, and debuggers.

Applications:

• Motion Control: Ideal for precise control in servo drives and stepper motors.
• Robotics: Capable of managing complex robotic systems efficiently.
• Numerical Control: Well-suited for CNC machine tools and other numerical control applications.
• Image Processing: Utilized in tasks like edge detection and pattern recognition within image processing applications.
• Signal Processing: Enables various signal processing tasks such as filtering, modulation, and demodulation.

Technical Specifications:

• Processor: 32-bit fixed-point DSP core
• Clock Speed: 200 MHz
• Memory:
  • On-Chip SRAM: 256 KB
  • Off-Chip SRAM: 1 MB
  • Flash Memory: 2 MB
