ABB INSEM11 Sequence of Events Master Module

Description

The INSEM11 module logs sequences of events with millisecond-level resolution, making it ideal for applications that demand accurate event tracking—such as power generation, oil & gas, and process industries. It integrates directly into ABB’s control architecture and supports real-time monitoring and event transfer to supervisory systems.

Specifications

• Model: INSEM11
• Function: Sequence of Events Master Transfer Module
• Event Logging Resolution: 1 ms
• Event Storage: Up to 1024 events in non-volatile memory
• Power Supply: 24 VDC (nominal), 5 W typical
• Communication Protocol: ABB Symphony network protocol
• Mounting: Rack-mounted in Symphony control cabinets
• Operating Temperature: –25°C to +60°C
• Storage Temperature: –40°C to +85°C
• Humidity: 5% to 95% RH, non-condensing
• Shock Resistance: 15 g, 11 ms (IEC 60068-2-27)
• Dimensions: Standard ABB DCS module size
• Weight: ~0.5–1.0 kg depending on variant

Key Features

• High-resolution event capture for precise sequence analysis
• Non-volatile memory ensures data retention during power loss
• Direct integration with ABB Symphony and Bailey Infi 90 systems
• DIN-rail or rack-mountable depending on configuration
• Robust design for harsh industrial environments
• Supports diagnostics and fault tracing in real time
