ABB RXRFP4LR 1KHL015107R0001 Redundant Remote I/O Module

Description

The ABB RXRFP4LR 1KHL015107R0001 is a redundant remote I/O module designed for integration into ABB’s AC800M Distributed Control System. It ensures high availability and reliable signal acquisition in demanding industrial environments.

Specifications

• Model Number: RXRFP4LR
• Part Number: 1KHL015107R0001
• Power Supply: 24V DC ±10%
• Nominal Power Consumption: 5W
• Insulation Resistance: ≥ 100 MΩ @ 500V DC
• Surge Protection: 1500V, IEC 60255-5 compliant
• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity Range: 10% to 95% RH, non-condensing
• Dimensions: 23 cm × 11 cm × 3.4 cm
• Weight: 0.35 kg
• Installation Method: DIN rail mounting
• Protection Rating: IP20 industrial-grade
• Communication Interfaces: Profibus DP, DeviceNet, Modbus

Features

• Redundant Communication: Dual-channel design ensures continuous data flow even during link failures
• Remote I/O Expansion: Supports deployment far from the main controller, reducing wiring complexity
• Signal Isolation & Protection: Built-in electrical isolation and overload/short-circuit protection
• Flexible I/O Configuration: Supports multiple input/output combinations (e.g., 16 DI + 16 DO)
• Online Diagnostics: Real-time monitoring of module status and communication quality
• System Compatibility: Seamless integration with ABB AC800M and other compatible platforms
• Industrial Reliability: Engineered for harsh environments like oil & gas, chemical, and power sectors
