ABB TC513V1 3BSE018405R1 AF100 Twisted Pair Coax Modem

General Information

• Product ID: 3BSE018405R1
• ABB Type Designation: TC513V1
• Catalog Description: TC513V1 AF100 Twisted Pair / Coax Modem
• Product Type: Communication Module
• Medium Description: TC513V1 AF100 Twisted Pair Coax Modem
• Country of Origin: Sweden
• Part Type: Standard Product

Technical Information

• Function: Converts between Advant Fieldbus 100 twisted pair and coaxial communication media
• Application: Used in AF100 networks for signal transmission between twisted pair and coax cables
• Power Supply: 24 V DC
• Rated Isolation: 50 V
• System: Advant Fieldbus 100

Dimensions & Weight

• Net Dimensions (L × W × H): 200 × 30 × 150 mm
• Net Weight: 0.725 kg

Environmental Information

• RoHS Compliance: Exempt under EU Directive 2011/65/EU
• WEEE Category: 5 – Small Equipment (no external dimension > 50 cm)
• Number of Batteries: 0
• SCIP Reference: dddc821c-b4a7-4676-9cf6-48f9e5f3ec72 (Sweden)
