Allen Bradley 1503VC-BMC3 Control Module

Description

The Allen Bradley 1503VC-BMC3 is an IntelliVAC Contactor Control Module designed for precise control of medium voltage motor applications. It integrates seamlessly with Bulletin 1502 vacuum contactors and enhances operational safety and efficiency through advanced diagnostics and arc flash mitigation.

Specifications

• Model Number: 1503VC-BMC3
• Type: IntelliVAC Contactor Control Module
• Rated Voltage: 600V AC
• Control Voltage: 110V AC
• Coil Voltage: 120V AC, 60 Hz
• Rated Current: 300A
• Power Supply: 120V AC / 240V AC or 110–250V DC
• Communication Interface: Fiber-optic connection
• Operating Temperature: -20°C to +60°C
• Altitude Compensation: Electronic (400A) or manual (800A) adjustment
• Dimensions: Approx. 11.5 cm × 31.7 cm × 16.0 cm
• Weight: ~1.41 kg
• Mounting Type: Panel-mounted
• Compliance: Meets industry standards for motor control
• Certifications: CE, UL (upon request)

Features

• Arc Flash Mitigation: Reduces risk of electrical hazards during operation
• Overload Protection: Safeguards motors from damage due to excessive current
• Fault Diagnostics: LED indicators and status relays for quick troubleshooting
• Power Loss Ride-Through: Maintains contactor closure during short power interruptions
• Jog Function: Allows temporary motor positioning for setup (electrically held contactors only)
• Anti-Kiss & Anti-Pumping Protection: Prevents unintended rapid re-closure
• Delayed Restart: Ensures safe duty cycle adherence
• Flexible Control: Supports both electrically held and mechanically latched contactors
• OEM Integration: Can be used as a loose component for third-party systems
