Allen Bradley 1585J-M8HBJM-1M9 Shielded Industrial Ethernet Cordset

Description

The 1585J-M8HBJM-1M9 is part of Allen Bradley’s 1585 series of Ethernet media products. It is a preassembled Cat5e shielded cordset designed for industrial Ethernet applications requiring reliable, noise-resistant connectivity. With straight RJ45 male connectors on both ends, it supports fast Ethernet communication over copper wiring.

Specifications

• Model: 1585J-M8HBJM-1M9
• Cable Type: Shielded Cat5e Ethernet cordset
• Cable Length: 1.9 meters
• Connector Type: RJ45 male to RJ45 male (straight)
• Number of Conductors: 8 (4 twisted pairs)
• Wire Gauge: 22 AWG
• Voltage Rating: 600V
• Bandwidth: 100BASE-TX, 100 Mbit/s
• Cable Outer Diameter: 8.13 mm
• Cable Rating: UL CMX, CMR, CMG, PLTC, AWM 2570
• Temperature Rating: 80°C
• Compliance: IEEE 802.3 Fast Ethernet

Features

• Industrial Shielding: Protects against electromagnetic interference in high-noise environments
• High-Speed Transmission: Supports 100BASE-TX Ethernet for fast and stable data flow
• Durable Construction: Thermoplastic Elastomer (TPE) jacket resists chemicals and mechanical stress
• Flexible Installation: Straight connectors simplify routing in control panels and machinery
• UL Listed: Meets multiple UL cable standards for safety and reliability
• Plug-and-Play: Preassembled for quick deployment in industrial networks
• Environmental Protection: Rated for M3I3C3E3 conditions per Rockwell standards
