Allen Bradley 1606-XL480EP Power Supply

Description

The Allen Bradley 1606-XL480EP is a standard switched-mode power supply module from the 1606 series. Designed for industrial automation, it provides stable 24V DC output at up to 20A, supporting parallel operation and high reliability in control panels and machinery.

Specifications

• Model: 1606-XL480EP

• Output Voltage: 24V DC (adjustable 24–28V)

• Output Current: 20A continuous, 25A peak

• Output Power: 480W continuous, 600W peak

• Input Voltage Range: 85–264V AC / 90–375V DC

• Efficiency: Up to 94%

• Mounting: DIN rail

• Dimensions: 12.2 × 5.49 × 13.34 cm

• Weight: Approx. 2.27 kg (5 lbs)

Features

• Wide Input Range: Operates across global voltage standards for flexible deployment

• Parallel Operation: Supports redundancy or power scaling via parallel connection

• High Efficiency: Up to 94% for reduced energy loss and heat generation

• Robust Protection: Includes overload, short-circuit, and overvoltage safeguards

• Compact Design: DIN rail mountable for space-constrained control cabinets

• Reliable Performance: Designed for continuous operation in harsh industrial environments

• Global Compliance: Meets international safety and performance standards
