Allen Bradley 1746-P2 Power Supply Module

Description

The Allen-Bradley 1746-P2 is a rack-mounted power supply designed for the SLC 500 modular controller system. It delivers regulated DC power to the backplane and user devices, supporting a wide range of industrial automation applications. This low-voltage AC model is ideal for systems requiring stable power delivery and high reliability.

Specifications

• Model: 1746-P2
• Series: SLC 500
• Nominal Input Voltage: 120/240V AC
• Input Voltage Range: 85–132V AC / 170–265V AC
• Frequency: 47–63 Hz
• Maximum Inrush Current: 20A
• Backplane Output Current: 5A @ 5V DC, 0.96A @ 24V DC
• User Output Voltage Range: 18–30V DC
• User Output Current: 0.2A @ 24V DC
• Power Consumption: Approx. 42W
• Isolation Rating: 1800V AC RMS for 1 second
• Ambient Operating Temperature: 0°C to +60°C
• Dimensions: 140 × 75 × 145 mm (5.5 × 2.9 × 5.7 in)
• Weight: Approx. 0.7 kg

Features

• Reliable Power Distribution: Supplies regulated DC power to SLC 500 modules
• Dual Voltage Input: Supports both 120V and 240V AC systems
• Compact Rack Mount Design: Fits seamlessly into SLC 500 chassis
• Integrated Overcurrent Protection: Includes fuse protection for short-circuit scenarios
• Wide Operating Range: Tolerates industrial temperature and voltage fluctuations
• Global Compliance: Meets UL, CSA, and CE standards for hazardous locations
• Quick Installation: Plug-and-play compatibility with SLC 500 systems
• Durable Construction: Built to withstand vibration and EMI/RFI interference
