Allen Bradley 1769SC-IF4IH 4 Point Analog Input Module

Description:

The 1769SC-IF4IH module supports multiple analog input types and provides advanced functionality through HART communication. It allows users to program and monitor HART-enabled devices directly from a single workstation, eliminating the need for additional tools.

Specifications:

• Input Signal Types: 0-20 mA, 4-20 mA, 0-5 V, 1-5 V, ±10 V
• Resolution: 16 bits
• Power Supply:
  • 120 mA @ 5V DC
  • 60 mA @ 24V DC
• Dimensions: 87 mm (Depth) x 118 mm (Height) x 16.104 mm (Length)
• Weight: 0.286 kg
• Operating Temperature: -20°C to +60°C

Features:

• HART Communication: Enables programming and monitoring of HART-enabled devices without additional bridges or handheld tools.
• User-Selectable Range: Supports custom range selection, process alarms, timestamping, and adjustable filter frequencies.
• Field Device Interface: Directly interfaces with field devices for streamlined operations.
• Compact Design: Fits seamlessly into CompactLogix and MicroLogix 1500 systems.
• Ease of Installation: Features a plug-and-play design for quick setup.
