Allen Bradley 1794-TB3TS Terminal Base Unit

Description

The Allen-Bradley 1794-TB3TS is a terminal base unit from the FLEX I/O 1794 series. It provides spring-clamp connections for FLEX I/O modules, supporting fast wiring and secure signal transmission in compact industrial control systems.

Specifications

• Catalog Number: 1794-TB3TS
• Series: FLEX I/O 1794
• Connection Type: Spring-clamp terminals
• Terminal Points: 36 connections
• Mounting Method: DIN rail or panel mount
• Voltage Rating: Up to 125V AC/DC
• Current Capacity: Up to 10 Amps
• Wiring Type: Cold junction compensation supported
• Compatibility: Designed for temperature modules and analog I/O
• Operating Temperature: –20°C to +60°C
• Storage Temperature: –40°C to +85°C
• Dimensions: Compact footprint for modular installations
• Lifecycle Status: Active mature product


Features

• Spring-Clamp Terminals: Enables fast, tool-free wiring with secure retention
• Cold Junction Support: Ideal for temperature sensing applications
• Modular Integration: Compatible with multiple FLEX I/O modules
• DIN Rail Mounting: Flexible installation in control panels
• High Current Handling: Supports up to 10 Amps for demanding loads
• Compact Design: Saves space in dense I/O configurations
• Reliable Signal Routing: Ensures stable communication across modules
• Industrial Grade: Built for rugged environments and long-term durability
