ATPS02 | ABB | Turbine Protection Slave Module

Description

The TPS02 module is part of ABB's Symphony Plus series, providing overspeed protection, trip functions, and hydraulic control for turbines. It integrates with INFI-NET communication highways and supports redundant configurations for enhanced reliability.

Specifications

• System Compatibility: Works within ABB's HR series turbine modules.
• Communication: INFI-NET protocol for seamless integration.
• Protection Functions:
• Overspeed Protection (OSP): Activates at 103% of rated speed.
• Trip Function (TRIP): Engages at 110% of rated speed.
• High-Pressure Shutdown (EHC): Ensures rapid turbine shutdown.
• Power Imbalance Protection (PLI): Monitors load distribution.
• Hydraulic Control:
• Solenoid Valves: Controls oil pressure for turbine shutdown.
• LVDT Sensors: Provides precise position feedback.
• Mounting: Rack-mounted for easy installation.
• Environmental Resistance: Designed for industrial conditions.

Features

• Advanced Turbine Protection: Ensures safe operation and prevents damage.
• Redundant System Support: Enhances reliability in critical applications.
• Real-Time Monitoring: Provides accurate turbine speed and load data.
• Seamless Integration: Compatible with ABB's Infi90 control system.
• Fault Diagnostics: Detects and reports system errors for proactive maintenance.
