Bachmann AIO288 Analog Input/Output Module

Description

The Bachmann AIO288 is a compact analog I/O module combining 8 inputs and 8 outputs for high-speed, high-accuracy signal processing in industrial automation systems.

Specifications

• Analog Inputs: 8 channels, single-ended or differential
• Input Types: ±10 V, ±1 V, 20 mA, Pt100/Pt1000 (2-/4-wire)
• Analog Outputs: 8 channels, ±10 V range
• Resolution: 14-bit for both input and output
• Sampling Time: 200 µs per channel
• Accuracy: ±0.1% full scale
• Temperature Inputs: Supports up to 4 Pt100/Pt1000 sensors
• Diagnostics: Wire break detection, overload protection
• Mounting: DIN rail compatible
• Dimensions: 120 × 75 × 30 mm
• Weight: Approx. 150 g

Features

• Dual Functionality: Combines analog input and output in one module
• Fast Response: 200 µs sampling enables real-time control
• High Precision: 14-bit resolution ensures accurate signal conversion
• Sensor Versatility: Supports voltage, current, and temperature sensors
• Robust Protection: Built-in diagnostics for safe operation
• Compact Design: Space-saving form factor for modular systems
• Easy Integration: Seamlessly fits into Bachmann automation platforms
