Bachmann DIO280 Digital Input/Output Module

Description

The Bachmann DIO280 is a digital input/output module designed for industrial automation applications. It provides high-density signal processing, making it suitable for controlling and monitoring various digital devices.

Specifications

• Manufacturer: Bachmann
• Model Number: DIO280
• Product Type: Digital Input/Output Module
• Input Channels: 80 digital channels
• Configurable Channels: 16 channels can be set as input or output
• Supply Voltage: 18 V DC to 34 V DC (reverse polarity protection)
• Interrupt Inputs: 8 configurable interrupt inputs
• Counter Support: Up to 4 configurable 32-bit counters
• PWM Output Mode: Supports pulse-width modulation for energy-efficient operation
• Status Indication: LED indicators for each channel
• Operating Temperature: -30°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity Tolerance: 5% to 95% (non-condensing)

Features

• Flexible Configuration: 16 channels can be set as either input or output.
• Interrupt-Driven Operation: Supports configurable interrupt inputs for enhanced responsiveness.
• Advanced Counter Functions: Includes event counting, incremental encoder support, gate time measurement, period duration, and frequency measurement.
• PWM Output Mode: Optimized for valve economy mode, reducing energy consumption.
• LED Status Display: Each channel has an LED indicator for clear signal monitoring.
• Industrial Durability: Designed to withstand harsh environmental conditions.
