Bently Nevada 330980-50-00 Proximity Transducer System

Description

The Bently Nevada 330980-50-00 is part of the 3300 XL NSv Proximity Transducer System, engineered for precise non-contact vibration and position measurements. It’s ideal for tight installation spaces and small target applications in compressors and rotating machinery.

Specifications

• Model: 330980-50-00
• Series: 3300 XL NSv
• Sensor Type: Proximitor Sensor
• System Length: 5.0 meters (16.4 feet)
• Mounting Option: Panel mount
• Power Supply: -17.5 VDC to -26 VDC (12 mA max)
• Operating Temperature: -52°C to +100°C
• Storage Temperature: -52°C to +105°C
• Humidity: 100% condensing, non-submersible
• Output Resistance: 50 Ω
• Weight: 255 g (9 oz)
• Compliance: CE Mark, EMC Directive 2004/108/EC

Features

• Compact Design: Slim profile for high-density DIN-rail or panel mounting
• High Accuracy: Average scale factor of 7.87 V/mm (200 mV/mil)
• Enhanced RFI/EMI Immunity: Suitable for fiberglass housings without shielding
• Flexible Compatibility: Works with 3300 RAM and NSv probes and extension cables
• Robust Construction: Gold-plated connectors and chemically resistant probe materials
• Wide Application Range: Ideal for radial/axial vibration, thrust position, and Keyphasor signals
• Upgrade-Friendly: Can replace older 3300 RAM and 190 series transducer systems
