Bently Nevada 330980-50-05 Proximitor Sensor

Description

The Bently Nevada 330980-50-05 is a Proximitor Sensor from the 3300 XL NSv series, designed for precision vibration and position measurements in space-constrained environments. It’s ideal for compressors and rotating machinery where traditional probes are too large or limited by mounting constraints.

Specifications

• Model: 330980-50-05
• Series: 3300 XL NSv
• Sensor Type: Proximitor Sensor
• System Length: 5.0 meters (16.4 feet)
• Mounting Option: Panel mount
• Operating Voltage: -17.5 VDC to -26 VDC
• Power Consumption: 12 mA max
• Operating Temperature: -52°C to +100°C
• Storage Temperature: -52°C to +105°C
• Humidity: 100% condensing (non-submersible)
• Output Resistance: 50 Ω
• Weight: 255 g (9 oz)
• Compliance: CE Mark, EMC Directive 2004/108/EC

Features

• Slim Profile: Designed for high-density DIN-rail or panel mounting
• High Sensitivity: Average scale factor of 7.87 V/mm (200 mV/mil)
• Enhanced RFI/EMI Immunity: Operates reliably in fiberglass housings without shielding
• Flexible Compatibility: Works with NSv probes and extension cables
• Robust Build: Gold-plated connectors and chemically resistant probe materials
• Versatile Applications: Suitable for radial/axial vibration, thrust position, and Keyphasor signals
• Upgrade-Friendly: Can replace older 3300 RAM and 190 series transducer systems
