Emerson DeltaV KJ3209X1-BA1 12P3905X012 Output Module

Description

Emerson DeltaV KJ3209X1-BA1 (P/N: 12P3905X012) is a 16-channel discrete output module designed for use with the DeltaV distributed control system. It provides reliable 24V DC sourcing outputs for actuators, solenoids, and other field devices, with built-in diagnostics and hot-swap capability for uninterrupted operation.

Specifications

• Model: KJ3209X1-BA1
• Part Number: 12P3905X012
• Channels: 16 discrete outputs
• Output Type: Sourcing (24V DC nominal)
• Output Voltage Range: 10–30V DC
• Maximum Output Current: 0.5A per channel
• Isolation: Optical isolation per channel
• Diagnostics: Open circuit, short circuit, and overcurrent detection
• Hot-Swap Capability: Yes
• Power Dissipation: < 2.5W typical
• Operating Temperature: –40°C to +70°C
• Mounting: DeltaV I/O carrier
• Dimensions: Standard DeltaV module form factor
• Weight: Approx. 0.3–0.5 kg
• Warranty: 12 month

Features

• Reliable Output Control: 16 sourcing channels for direct control of field devices
• Advanced Diagnostics: Real-time fault detection for improved system reliability
• Hot-Swappable: Enables maintenance without system shutdown
• DeltaV Integration: Seamless operation within Emerson’s DeltaV DCS architecture
• Industrial Durability: Designed for harsh environments and continuous operation
• Flexible Application: Suitable for process control, batch automation, and discrete manufacturing
• Global Compliance: Certified for use in hazardous and regulated environments
