Emerson Epro CON021+PR6423/010-000 Eddy Current Sensor System

Description

The Emerson Epro CON021+PR6423/010-000 is a high-precision eddy current sensor system used for non-contact vibration and displacement monitoring in critical rotating machinery. Ideal for steam turbines, gas turbines, compressors, and gearboxes, it ensures reliable diagnostics in harsh industrial environments.

Specifications

• System Model: CON021 signal converter + PR6423/010-000 sensor
• Measurement Range: 2 mm (80 mils) linear range
• Initial Air Gap: 0.5 mm (20 mils)
• Sensitivity: 8 V/mm (203.2 mV/mil) ±5% @ 0–45°C
• DSL Accuracy: ±0.025 mm (±1 mil)
• Frequency Response: 0 to 20,000 Hz (–3 dB)
• Operating Temperature:
  • Sensor: –35°C to +200°C
  • Cable/Connector: –35°C to +150°C
• Protection Class: IP66 (IEC 60529)
• Sensor Tip Material: PEEK
• Housing: Stainless steel
• Cable: PTFE
• Connector: Brass, nickel-plated
• Minimum Shaft Diameter: 25 mm
• Certifications: CE, RoHS, ATEX, IECEx, CSA
• Weight: Approx. 100 g (sensor with 1 m cable)


Features

• Non-Contact Measurement: Captures radial and axial shaft displacement with high precision
• High Sensitivity: 8 V/mm output ensures accurate vibration diagnostics
• Wide Temperature Range: Operates reliably in extreme thermal conditions
• Robust Construction: IP66-rated and built with corrosion-resistant materials
• Flexible Integration: Compatible with Emerson MMS 3000/6000 monitoring systems
• Global Compliance: Meets international standards for hazardous area operation
