Emerson Epro CON021+PR6423/010-030 Eddy Current Sensor

Description

The Emerson Epro CON021+PR6423/010-030 is a high-precision eddy current sensor system designed for critical turbomachinery applications. It provides non-contact measurement of shaft displacement, position, and vibration, ensuring reliable monitoring in environments such as steam turbines, compressors, and gearboxes.

Specifications

• Sensor Type: PR6423/010-030 Eddy Current Probe
• Converter Module: CON021 Signal Converter
• Measurement Range: 3.0 mm (Extended Range)
• Linearity Error: ≤ 1.5%
• Frequency Response: 0 to 20,000 Hz
• Rise Time: <15 μs
• Supply Voltage: –21 V to –32 V DC
• Output Voltage Range: –2 V to –18 V DC
• Operating Temperature: –35°C to +200°C (sensor), –30°C to +100°C (converter)
• Protection Class: IP66 (sensor), IP20 (converter)

Features

• Non-Contact Measurement: Ideal for dynamic shaft displacement and vibration monitoring
• High Temperature Tolerance: Operates reliably in extreme thermal conditions
• Robust Construction: Built with corrosion-resistant materials for harsh industrial environments
• Advanced Diagnostics: Supports real-time monitoring and fault detection
• Flexible Integration: Compatible with a wide range of Emerson monitoring systems
• Long-Distance Transmission: Fiber optic options available for extended reach
• Intrinsic Safety: Certified for use in hazardous areas with proper barriers
• Precision Performance: Maintains accuracy and stability across wide frequency and temperature ranges
