Emerson Epro CON021+PR6424/010-040 Eddy Current System

Description

The Emerson Epro CON021+PR6424/010-040 is an eddy current displacement sensor system designed for high-precision monitoring of rotating machinery. It is widely used in turbines, compressors, and pumps, providing accurate measurements of shaft displacement, vibration, and position. The PR6424 sensor enables non-contact measurement, while the CON021 signal converter processes the data for reliable diagnostics.

Specifications

• Frequency Range: 0 to 20,000 Hz
• Response Time: <15 μs
• Operating Temperature: -30°C to +100°C
• Shock & Vibration Resistance: 5g @ 60 Hz @ 25°C
• Protection Class: IP20
• Supply Voltage Range: -23V to -32V DC
• Output Voltage Range: -4V to -20V DC
• Measurement Range: ±2.0 mm (dynamic)
• Sensitivity: 8 V/mm (203.2 mV/mil)
• Target Material: Ferromagnetic steel
• Cable Material: PTFE (optional armored cable available)

Features

• High-precision eddy current sensing, ensuring reliable machinery monitoring
• Non-contact measurement, minimizing wear and tear
• Wide operating temperature range, making it suitable for harsh industrial environments
• Modular design, allowing easy integration into monitoring systems
• ATEX & IECEx certified, ensuring intrinsic safety in hazardous areas
• Seamless compatibility with Emerson’s predictive maintenance solutions
