Emerson Epro CON021 + PR6424/010-110 Eddy Current Sensor System

Description

The Emerson Epro CON021 + PR6424/010-110 is a high-precision, non-contact eddy current sensor system designed for dynamic monitoring of shaft displacement, vibration, and position in critical rotating machinery. It’s ideal for turbines, compressors, and pumps operating in harsh industrial environments.

Specifications

• Sensor Type: Eddy current displacement sensor system
• Sensor Model: PR6424/010-110
• Converter Model: CON021
• Measurement Range: 2 mm (PR6424/010-110)
• Sensitivity: 8 V/mm ±5%
• Initial Air Gap: 0.5 mm
• Frequency Range: 0 to 20,000 Hz
• Rise Time: <15 μs
• Sensor Operating Temperature: -35°C to +180°C
• Converter Operating Temperature: -30°C to +100°C
• Protection Class: Sensor – IP66; Converter – IP20
• Power Supply Voltage: -23V to -32V
• Output Voltage Range: -4V to -20V or -2V to -18V
• Sensor Material: Tip – PEEK; Case – Stainless Steel; Cable – PTFE
• Converter Housing: LMgSi 0.5 F22
• Mounting: 4 x M5x20 screws
• Weight: Sensor – ~100g; Converter – ~120g

Features

• Non-Contact Measurement: Enables accurate monitoring of shaft vibration and displacement
• High Temperature Tolerance: Sensor withstands up to +180°C for demanding applications
• Fast Response: Converter rise time under 15 μs supports dynamic machinery diagnostics
• Robust Construction: Stainless steel and PEEK materials ensure durability in harsh conditions
• Wide Frequency Range: Suitable for high-speed rotating equipment
• Flexible Integration: Compatible with various monitoring systems and safety barriers
• Hazardous Area Approved: Certified for use in explosive environments (ATEX, IECEx)
• Compact & Lightweight: Easy to install in tight control cabinet spaces
