Emerson KJ1501X1-BC2 Dual DC Power Supply

Description

The KJ1501X1-BC2 module provides reliable and consistent power to various components within the DeltaV system, ensuring uninterrupted operation and optimal performance in industrial automation and process control applications.

Specifications

• Input Rating:
  • 12 VDC at 14.8 A
  • 24 VDC at 6.1 A
• Output Rating:
  • 12 VDC at 13 A (when input is 12 VDC)
  • 12 VDC at 8 A (when input is 24 VDC)
  • 5.1 VDC at 2.0 A
  • 3.4 VDC at 2.0 A
• Output Power: 10.2 W (total from +5.1 VDC and +3.4 VDC)
• Weight: 0.7 kg

Environmental Specifications

• Ambient Temperature: -40°C to +70°C
• Shock Resistance: 10g 1⁄2 Sinewave for 11 msec
• Vibration: 1 mm Peak to Peak from 2 to 13.2 Hz; 0.7g from 13.2 to 150 Hz
• Airborne Contaminants: ISA-S71.04 –1985 Airborne Contaminants Class G3
• Relative Humidity: 5% to 95% non-condensing
