Emerson KJ1710X1-BA1 Single Port Fiber Switch

Description

The KJ1710X1-BA1 is an ATEX-approved fiber switch, built for industrial automation systems requiring high-speed fiber optic communication. It supports intrinsically safe operation, making it suitable for hazardous locations. The switch is part of Emerson’s DeltaV system, ensuring seamless integration with process control networks.

Specifications

• Power Input: +19.2 to 28.8 VDC at 250 mA
• Environmental Ratings:
  • Operating Temperature: -40°C to +70°C
  • Shock Resistance: 10G (½-sinewave for 11 ms)
  • Vibration Resistance: 1 mm peak-to-peak (5 Hz to 16 Hz), 0.5 g (16 Hz to 150 Hz)
  • Airborne Contaminants: ISA-S71.04 –1985 Class G3
  • Humidity: 5% to 95% (non-condensing)
• Safety Approvals:
  • ATEX Certification: II 3G ExnA [op is] IIC T4
  • NI Class I, Division 2 (Groups A, B, C, D)
  • AIS Class I, Division 1 (Groups A, B, C, D)

Features

• Hazardous Area Compatibility: Designed for explosive environments, ensuring safe operation.
• Robust Power Specifications: Operates within wide voltage ranges, supporting stable performance.
• High-Speed Fiber Communication: Enables efficient data transfer in industrial networks.
• Shock & Vibration Resistance: Built to withstand harsh mechanical conditions.
• Seamless Integration: Works with Emerson DeltaV systems, ensuring optimized process control.
