Emerson KJ3241X1-BA2 Serial Interface Card

Description

The Emerson KJ3241X1-BA2 is a high-reliability Serial Interface Card designed for seamless integration within DeltaV distributed control systems (DCS). It supports robust serial communication across industrial environments, ensuring dependable data exchange and system performance.

Specifications

• Type: Serial Interface Card
• Compatible Systems: DeltaV DCS
• Input Power: 12V DC @ 300 mA (via local bus)
• Number of Ports: 2 independent serial ports
• Supported Protocols: Modbus RTU, ASCII, and custom serial formats
• Baud Rate Range: 300 to 115200 bps
• Serial Isolation: 1500V DC
• Power Dissipation: Approximately 3.6W
• Installation Method: Plug-in card for DeltaV I/O subsystem
• Operating Temperature: -40°C to +70°C
• Relative Humidity: 5–95% (non-condensing)
• Dimensions: Width 11.7 cm, Height 12.2 cm, Depth 4.5 cm
• Weight: 0.35 kg

Features

• Communication Support: RS-232, RS-422, RS-485 protocols
• Multi-Drop Capability: Supports up to 32 devices per port
• Flexible Configuration: Selectable baud rates, parity, and stop bits
• Isolation: Galvanically isolated ports for enhanced signal integrity
• Error Detection: Advanced diagnostics for communication integrity
• Environmental Resilience: Operates reliably across wide temperature and humidity ranges
• Redundancy Support: Ensures uninterrupted operation under fault conditions
• Compact Design: Space-efficient and energy-conscious for industrial deployment
