Emerson KJ4001X1-CF1 Mass Terminal Block

Description

The Emerson KJ4001X1-CF1 is a 24-pin Mass Terminal Block engineered for use in DeltaV™ Electronic Marshalling systems. It provides a reliable and organized interface for field wiring, especially in hazardous industrial environments where safety, durability, and ease of integration are critical.

Specifications

• Part Number: KJ4001X1-CF1
• Product Type: 24-Pin Mass Terminal Block
• Input Power Rating: 30 VDC @ 1 A
• Operating Temperature: -40°C to +70°C
• Shock Resistance: 10 g, half-sine wave for 11 ms
• Vibration Resistance:
  • 1 mm peak-to-peak (2–13.2 Hz)
  • 0.7 g (13.2–150 Hz)
• Humidity: 5% to 95% non-condensing
• Airborne Contaminants: ISA-S71.04 Class G3
• Mounting: DIN rail or carrier-based
• Certifications:
  • ATEX II 3G Ex ec IIC Gc
  • IECEx, FM, UKEX, CSA (Zone 2/Class I Div 2)
• Country of Origin: United States

Features

• DeltaV™ System Integration: Seamlessly connects with Emerson’s DeltaV Electronic Marshalling architecture
• Hazardous Area Certified: Approved for use in explosive and classified environments
• Robust Construction: Built to withstand industrial shock, vibration, and temperature extremes
• Simplified Wiring: 24-pin layout supports efficient and organized field connections
• Maintenance-Free: No user-serviceable parts; calibration not required
• Safe Operation: Must be installed or removed with system power off, ensuring safety compliance
