Emerson KJ4005X1-BA1 S-Series System Carrier

Description

The Emerson KJ4005X1-BA1 is an S-Series System Carrier designed for DeltaV™ distributed control systems. It provides the mechanical and electrical backbone for mounting I/O modules, power supplies, and controllers, ensuring reliable operation in industrial automation environments, including hazardous areas.

Specifications

• Part Number: KJ4005X1-BA1
• Product Type: S-Series System Carrier
• Local Bus Power: 12 VDC at 15 A
• Field Power (8-Wide Carrier): 30 VDC at 3 A per card
• Operating Temperature: -40°C to +70°C
• Shock Resistance: 10 g, ½ sine wave for 11 ms
• Vibration Resistance:
  • 1 mm peak-to-peak (2–13.2 Hz)
  • 0.7 g (13.2–150 Hz)
• Humidity: 5% to 95% non-condensing
• Airborne Contaminants: ISA-S71.04 Class G3
• Dimensions: 4.3 cm × 12.6 cm × 16 cm
• Weight: Approx. 0.77 kg
• Certifications:
  • ATEX II 3G Ex ec IIC Gc
  • IECEx, FM, UKEX, CSA (Zone 2 / Class I Div 2)
• Mounting: DIN rail or carrier-based
• Maintenance: No user-serviceable parts; calibration not required

Features

• Modular Backbone: Supports installation of I/O modules, power supplies, and controllers
• Hazardous Area Certified: Safe for use in Zone 2 and Class I Div 2 environments
• Robust Construction: Withstands industrial shock, vibration, and temperature extremes
• Safe Operation: Must be installed or removed with system power off
• System Integration: Seamlessly connects with DeltaV™ S-Series architecture
• Protective Design: Requires module covers for unoccupied slots to maintain safety compliance
