Emerson KJ4005X1-BA1 S-Series System Carrier

Description

The Emerson KJ4005X1-BA1 is a robust S-Series System Carrier designed for DeltaV™ digital automation systems. It provides reliable power distribution and modular support for I/O and controller modules, making it ideal for demanding industrial environments.

Specifications

• Model Number: KJ4005X1-BA1
• Type: S-Series System Carrier
• Local Bus Power: 12 VDC at 15 A
• Field Power (8-Wide Carrier): 30 VDC at 3 A per card
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Shock Resistance: 10 g, ½ sine wave for 11 ms
• Vibration Resistance: 1 mm peak-to-peak (2–13.2 Hz), 0.7 g (13.2–150 Hz)
• Humidity: 5% to 95%, non-condensing
• Airborne Contaminants: ISA-S71.04 Class G3

Features

• Modular Design: Supports flexible system expansion and maintenance
• Hazardous Area Compliance: Certified for use in Zone 2 and Class I Div 2 environments
• Durable Construction: Engineered for harsh industrial conditions
• Easy Integration: Seamlessly fits into DeltaV S-Series architecture
• Safety-Oriented: Requires de-energized power for safe insertion/removal
• Compact Dimensions: 4.3 cm x 12.6 cm x 16 cm; Weight: 0.77 kg
• Maintenance-Free: No calibration or internal servicing required
