EPRO CON031 Eddy Current Signal Converter
EPRO CON031 Eddy Current Signal Converter
EPRO CON031 Eddy Current Signal Converter

    EPRO CON031 Eddy Current Signal Converter

      Description

      Dynamic Performance:

      • Frequency Range (-3 dB): 0 to 20,000 Hz
      • Rise Time: <15 µs

      Environmental:

      • Operating Temperature Range: -30 to 100°C (-22 to 212°F)
      • Shock and Vibration: 5g @ 60 Hz @ 25°C (77°F)
      • Protection Class: IP20

      Power & Electrical:

      • Supply Voltage Range:
        • -23V to -32V (Output Range -4V to -20V)
        • -21V to -32V (Output Range -2V to -18V)

      Physical:

      • Housing Material: ALMgSi 0.5 F22
      • Weight: ~120 grams (4.24 oz)
      • Mounting: 4 Screws M5x20 (Included in Delivery)
      • Connections (Screw terminal): (max. 1.5mm², wire-end sleeves)

      Hazardous Area Approvals:

      • Intrinsic Safety (iA):ATEX II 2 G Ex ia IIC T4 Gb, -20°C ≤ Ta ≤ 80°C (Use with current limiting, e.g.: safety barrier)
      • IEC-Ex: Ex ia IIC T4 Gb, -20°C ≤ Ta ≤ 80°C (Use with current limiting, e.g.: safety barrier)
      • CSA:Class I Division 1, Groups A, B, C, D, T4 T4: -25°C ≤ Ta ≤ 80°C (Use with current limiting, e.g.: safety barrier)
      • Non-sparking (nA):CSA Class I Division 2, Groups A, B, C, D Ex nA II T3…T4 AEx nA II T3…T4 T4: -25°C ≤ Ta ≤ 80°C


      NEW AND ORIGINAL ITEM IN STOCK

      WITH ONE YEAR WARRANTY
