EPRO MMS 3120/022-000 Dual Channel Bearing Vibration Transmitter for Seismic Sensors

The EPRO MMS 3120/022-000 Dual Channel Bearing Vibration Transmitter offers exceptional flexibility with multiple hardware options and versatile configuration possibilities. It is suitable for operating sensors in explosive environments and accurately measures and processes absolute bearing vibration signals.

Key Features:

• Highly flexible with various hardware options
• Precisely adaptable through versatile combination possibilities
• Suitable for explosive area sensor operation
• Measures and processes absolute bearing vibration signals
• Integrated microcontroller
• Compliant with VDI 2056/.. and API 670 standards
• Two redundant 24 V DC supply inputs
• Supervision functions for electronics and sensors
• Mountable directly on the machine

Function and Design:
The transmitter converts vibration transducer signals into two independent signals proportional to vibration velocity or amplitude. It features integrated module and sensor supervision to detect faults, with configurable outputs and options for customization.

Technical Data:

• Sensor inputs: Two independent inputs for seismic vibration sensors
• Measuring ranges: Configurable via software
• Output options: Current outputs, galvanically separated outputs, or without current output
• Data interfaces: RS232 interface standard, optional RS485 bus or PROFIBUS DP
• Power supply: Redundant option available
• Housing: Aluminum construction, IP65 protection
• Environmental conditions: Operating temperature range from -20°C to +65°C, humidity up to 95%
• Vibration and shock resistance: Shock resistance up to 20 g over 2 ms, vibration resistance up to 5 g at 60 Hz

Module and Sensor Supervision:
Continuous monitoring of input signal range, cable integrity, and system voltages, with signaling through function outputs.

NEW AND ORIGIN ITEM IN STOCK
WITH ONE YEAR WARRANTY

Hope anyone inquires from us, please click this sales7@cambia.cn
