Description
Specifications
- Sensitivity/Linearity: 4 V/mm (101.6 mV/mil) ±1.5% max
- Air Gap (Center): Approximately 2.7 mm (0.11 inches)
-
Nominal Range:
- Static: ±2.0 mm (0.079 inches)
- Dynamic: 0 to 1,000 µm (0 to 0.039 inches)
- Shaft Diameter: ≥80 mm
- Weight (Sensor & 1M Cable, No Armor): 200 grams (7.05 oz)
Features
- Non-contact Measurement: Measures displacement without contacting the measured surface
- Rugged Construction: Designed for critical turbomachinery applications such as steam, gas, compressor, and hydro turbines
- High Accuracy: Capable of accurately determining parameters of conductive materials
EPRO PR6423/00R-111 8mm Eddy Current Sensor
- SKU
- PR6423/00R-111
- Manufacturer
- Emerson
- Product Type
- Eddy Current Sensor
- Product Origin
- Germany
- Condition
- Brand New
- Payment
- T/T
- Weight
- 0.5 kg
- Shipping port
- Xiamen
- Warranty
- 12 months
Description
Specifications
- Sensitivity/Linearity: 4 V/mm (101.6 mV/mil) ±1.5% max
- Air Gap (Center): Approximately 2.7 mm (0.11 inches)
-
Nominal Range:
- Static: ±2.0 mm (0.079 inches)
- Dynamic: 0 to 1,000 µm (0 to 0.039 inches)
- Shaft Diameter: ≥80 mm
- Weight (Sensor & 1M Cable, No Armor): 200 grams (7.05 oz)
Features
- Non-contact Measurement: Measures displacement without contacting the measured surface
- Rugged Construction: Designed for critical turbomachinery applications such as steam, gas, compressor, and hydro turbines
- High Accuracy: Capable of accurately determining parameters of conductive materials
EPRO PR6423/00R-111 8mm Eddy Current Sensor
