FC-USI-0002 | Honeywell | Safety Manager System Module

Description

The Honeywell FC-USI-0002 is a Universal Safety Interface module designed for Safety Manager systems. It facilitates secure and reliable communication between the Safety Manager and external devices, including Experion PKS and Safety Builder environments.

Specifications

• Processor: Motorola 8260 communication processor
• Memory: 8 MB Flash, 8 MB SRAM with error detection and correction
• Shared RAM: 256 KB for data exchange with Control Processor
• Communication Channels: 4 independent channels (Ethernet and Serial)
• Ethernet Ports: Dual-speed transceivers (10/100 Mb, auto-ranging)
• Serial Ports: Two general-purpose serial communication controllers
• Connectors: RJ45 for Ethernet, 10-pin AMP for Serial
• LED Indicators: Status, Tx, Rx for each channel
• Reset Mechanisms: Power-up, power-dip, or STOP mode via Quad Processor Pack
• Installation: Mounted in Controller chassis, hot-swappable

Features

• Multi-Protocol Support: Handles demanding protocols in parallel
• Hardware Firewall: Protects internal safety functions from external threats
• EEPROM Storage: Retains MAC addresses and hardware revision data
• Flash Upgradable: System and application programs can be updated without removal
• Real-Time Diagnostics: LED indicators for transmission, reception, and module health
• Robust Communication: Ensures high-integrity data exchange across platforms
• System Integration: Seamlessly connects with Experion PKS and other Honeywell systems
• Safety-Critical Design: Engineered for use in certified safety environments
