Foxboro FBM217 P0916PW Discrete Input Interface Module

Description

The Foxboro FBM217 P0916PW is a discrete input interface module designed for use in I/A Series control systems. It provides 32 isolated input channels for monitoring digital signals from field devices, supporting both single and redundant configurations for high availability in industrial automation environments.

Specifications

• Model Number: FBM217
• Part Number: P0916PW
• Input Channels: 32 group-isolated discrete inputs
• Input Voltage Ranges:
  • 15 to 60 VDC
  • 120 VAC / 125 VDC
  • 240 VAC
• On-State Voltage: 15–30 VDC
• Off-State Voltage: 0–5 VDC
• Input Current: 2.2 mA (typical) at 30 VDC
• Filter/Debounce Time: Configurable (No filtering, 4, 8, 16, or 32 ms)
• Pulse Count Rate: Up to 250 Hz
• Power Supply: 24 VDC ±5%, –10%
• Power Consumption: Max 3 W
• Communication: Redundant 2 Mbps Fieldbus
• Operating Temperature: –20°C to +70°C
• Humidity: 5–95% RH, non-condensing
• Mounting: DIN rail baseplate
• Dimensions (HxWxD): Approx. 10.2 × 11.4 × 4.5 cm
• Weight: ~0.6 kg


Features

• High Channel Density: Supports 32 discrete inputs in a compact form
• Redundancy Ready: Can be deployed in redundant pairs for fault tolerance
• Flexible Voltage Support: Accepts a wide range of AC and DC input levels
• Rugged Design: Suitable for Class G3 harsh environments
• Advanced Diagnostics: Supports Sequence of Events (SOE) and fault detection
• Modular Integration: Compatible with various Termination Assemblies (TAs)
• Hot-Swappable: Allows replacement without disrupting field wiring or power
• Visual Indicators: LEDs for module status and input point activity
