GE DS200PCCAG6ACB Power Connect Card

Description

The GE DS200PCCAG6ACB is a Power Connect Card Assembly designed for the Mark V series of turbine control systems. It functions as an interface between the drive and the silicon-controlled rectifier (SCR) power bridge, ensuring efficient power distribution and voltage regulation.

Specifications

• Part Number: DS200PCCAG6ACB
• Series: Mark V
• Manufacturer: General Electric (GE)
• Product Type: Power Connect Card Assembly
• Functional Acronym: PCCA
• Voltage Range:
  • Regenerative: 240–630V
  • Non-Regenerative: 240–700V
• Group Classification: Group 6 (based on voltage and power conversion type)
• Connectors: 12 plug connectors for SCR bridge signal transmission
• PCB Coating: Normal coating
• Dimensions: Approx. 200 mm x 150 mm x 50 mm
• Weight: 0.68 lbs
• Operating Temperature: 0°C to +60°C

Features

• SCR Interface: Provides gate pulse signals to the SCR bridge for voltage control
• Signal Routing: Includes connectors like 1RPL–6RPL and 1FPL–6FPL for forward/reverse signals
• Power Supply Communication: 5PL connector interfaces with the power supply board
• Voltage Selection: Supports DC armature voltage range selection
• Drive Configuration Support: Works with parameter files and control panel inputs
• Application Flexibility: Suitable for both regenerative and non-regenerative systems
• System Integration: Seamlessly integrates into GE’s Mark V Speedtronic control architecture
