GE DS200SDCIG1AHB DC Power Supply Board

Description

The GE DS200SDCIG1AHB is a DC Power Supply and Instrumentation Board designed for the Mark V Speedtronic turbine control system. It provides regulated power and signal interfacing for critical control functions, supporting applications in gas, steam, and wind turbine systems.

Specifications

• Part Number: DS200SDCIG1AHB
• Series: Mark V Speedtronic
• Manufacturer: General Electric (GE)
• Board Type: SDCI – DC Power Supply and Instrumentation Board
• Power Interface: Supports DC2000 drive systems
• PCB Coating: Normal conformal coating
• Revisions: Functional Rev 1: A, Rev 2: H, Artwork Rev: B
• Dimensions: Approx. 8.5 cm × 7.1 cm × 3 cm
• Weight: Around 2.00 lbs (0.91 kg)
• Mounting: VME rack-compatible
• Environmental Rating: Industrial-grade durability

Features

• Power Distribution: Supplies regulated DC power to various control components
• Instrumentation Interface: Handles signal processing for turbine monitoring and diagnostics
• Fuse Monitoring: Each fuse includes an LED indicator for quick fault identification
• Configuration Options: Multiple jumpers and switches for flexible setup
• System Integration: Interfaces with DC2000 drives and other Mark V modules
• Legacy Support: Compatible with legacy GE Speedtronic systems
• Protective Design: Built to withstand harsh industrial environments with reliable performance
