GE DS2020DACAG2 Power Conversion Module

Description

The GE DS2020DACAG2 is a high-performance power conversion module designed for turbine and industrial control systems. It provides stable DC output, energy storage, and redundancy features to maintain continuous operation even under demanding conditions.

Specifications

• Model Number: DS2020DACAG2
• Type: AC/DC Converter Board
• Input Voltage: 115 VAC or 230 VAC
• Output Voltage: 125 VDC regulated
• Efficiency: >90% with industrial-grade semiconductor design
• Protection: Overcurrent, overvoltage, short-circuit protection (IEC 60950 compliant)
• Communication Interfaces: Ethernet (10/100Base-TX), RS-485
• Protocols Supported: Modbus TCP/RTU for monitoring and diagnostics
• Operating Temperature: -40 °C to +85 °C
• Storage Temperature: -40 °C to +85 °C
• Environmental Rating: IP65, EMC EN 55022 Class B
• Dimensions: ~35 mm standard industrial module width
• Applications: GE EX2100 Excitation Control, Speedtronic Mark V turbine systems


Features

• Reliable Power Conversion: Converts AC input to stable 125 VDC for turbine and control modules
• Energy Storage: Maintains operation during power interruptions with local storage capability
• Redundancy Support: Allows parallel operation for higher current output and automatic failover
• Industrial Durability: Wide temperature range and EMC shielding for harsh environments
• Smart Monitoring: Real-time voltage, current, and temperature diagnostics via Ethernet/RS-485
• Seamless Integration: Compatible with GE Speedtronic Mark V and EX2100 systems
