GE Fanuc IC695ALG616 Analog Input Module

Description

The GE Fanuc IC695ALG616 is a high-density, non-isolated analog input module from the PACSystems RX3i series. Designed for versatility, it serves as a universal interface that can process a wide variety of signal types—including voltage, current, and temperature sensors—within a single slot to streamline your control system architecture.

Specifications

• Module Type: Non-isolated universal analog input
• Channel Count: 16 single-ended or 8 differential channels
• Resolution: 16-bit analog-to-digital converter
• Input Ranges: 0 to 10V, ±10V, 0 to 20mA, 4 to 20mA
• Power Consumption: 450mA at 5VDC and 100mA at 3.3VDC from the backplane
• Update Rate: Dependent on the number of active channels and selected filter frequency

Features

• Universal Input Support: Handles voltage, current, resistance, RTD, and Thermocouple signals without needing multiple specialized modules.
• On-board Diagnostics: Provides real-time alerts for open wire detection, over-range, under-range, and hardware failure.
• Hot-Swappable: Supports insertion and removal from the RX3i backplane while the system is under power to minimize downtime.
• Configurable Digital Filtering: Allows users to select 50Hz or 60Hz line noise rejection to ensure high signal integrity in noisy environments.
• Cold Junction Compensation: Features built-in sensors to ensure accurate temperature readings when using thermocouples.
