GE Fanuc IC695CPU310 Central Processing Unit

Description

The GE Fanuc IC695CPU310 is a high-performance CPU module from the PACSystems RX3i series, designed for real-time control of machines, processes, and material handling systems.

Specifications

• Manufacturer: GE Fanuc
• Model Number: IC695CPU310
• Product Type: CPU Module
• Microprocessor: RX3i VME 300 MHz
• Clock Speed: 300 MHz
• User Memory: 10 MB battery-backed RAM + 10 MB non-volatile flash memory
• Serial Ports: 2 (RS-232 and RS-485)
• Execution Speed: 0.195 milliseconds per 1,000 Boolean instructions
• Maximum Program Blocks: 512
• Block Size: 128 KB
• Communication Protocols: Modbus RTU Slave, Serial I/O, SNP
• Operating Temperature: 0°C to 60°C
• Power Requirements:
  • +3.3 VDC: 1.25 Amps nominal
  • +5 VDC: 1.0 Amps nominal

Features

• High-Speed Processing: Executes Boolean instructions in 0.195 milliseconds, ensuring fast response times.
• Dual Backplane Compatibility: Supports PCI backplane for advanced I/O and serial backplane for legacy Series 90-30 I/O.
• Flexible Programming: Supports Ladder Diagram, Structured Text, Function Block Diagram, and C programming.
• Large Memory Capacity: Offers 10 MB battery-backed RAM and 10 MB non-volatile flash memory for data retention.
• Robust Communication: Features dual serial ports and Modbus RTU Slave support for seamless integration.
