GE IC694CHS392 10-Slot Serial Expansion Backplane

Description

This IC694CHS392 backplane is engineered to expand the I/O capacity of RX3i systems, providing a reliable platform for connecting additional modules. It supports high-speed serial communication and is ideal for industrial automation applications requiring scalability and flexibility.

Specifications

• Type: Serial Expansion Backplane.
• Number of Slots: 10 slots for I/O modules.
• Power Supply Compatibility: Works with IC694PWR321, IC694PWR330, and IC694PWR331 power supplies.
• Bus Connector: Includes a bus expansion connector for additional backplanes.
• Cable Length: Supports up to 15 meters (50 feet) of expansion cable.
• Operating Temperature: 0°C to 60°C (32°F to 140°F).
• Dimensions: Approximately 5.12 x 17.44 x 5.59 inches (H x W x D).

Features

• High Capacity: Accommodates up to 10 I/O modules for expanded system functionality.
• Reliable Communication: Ensures stable and efficient data transfer between modules.
• Ease of Installation: DIP switches for rack number selection simplify setup.
• Durable Design: Built to withstand industrial environments.
• Scalable: Supports additional backplanes for larger systems.
