GE IC697ALG320 Analog Output Module
Description
key features and specifications:
-
Functionality:
- Facilitates expansion from the main CPU rack by allowing additional modules to be added.
- Supports up to seven additional IC697 PLC racks.
- Provides a high-performance parallel interface to the programming device.
-
Interface:
- The module has two connectors:
- Top connector for attachment to the programming device.
- Bottom connector for a daisy-chained arrangement through Bus Receiver Modules to expansion racks.
- The module has two connectors:
-
Indicators:
- Three green LEDs provide status indication of each port and module status.
-
Configuration:
- Must be configured into the IC697 PLC system using the MS-DOS or Windows programming software configuration function.
-
Installation:
- Can be installed in any slot (except slot 1) in the main CPU rack.
-
Power Requirements:
- Requires 5 Volts DC voltage from the system backplane and draws 1.4 Amps of current.
-
Programmer Interface Specifications:
- The data rate of the programmer interface is 500 kilobytes per second.
- Supports a maximum cable length of 50 feet.
