GE IC697CPU780 CPU Module

Description

The GE IC697CPU780 is a high-performance CPU module from the Series 90-70 PLC family, engineered for critical industrial applications requiring high availability. It supports hot standby redundancy and advanced control capabilities, making it ideal for mission-critical automation systems.

Specifications

• Processor: Intel 80386DX, 16 MHz
• Execution Speed: 0.4 microseconds per Boolean function
• Memory: Supports up to 512 KB of battery-backed RAM and 512 KB of flash memory
• I/O Capacity: Up to 12K discrete and 8K analog I/O points
• Power Requirements: 5V DC, 1.6 A (including expansion memory)
• Communication Port: RS-485 serial interface
• Mounting Slot: Slot 1 of rack 0
• Battery Backup: Lithium battery (IC697ACC701), 10-year shelf life
• LED Indicators: Module OK, RUN, Outputs Enabled, Memory Protect
• Operating Temperature: 0°C to 60°C
• VME Bus Support: Compliant with VME C.1 standard

Features

• Hot Standby Redundancy: Enables bumpless CPU switching for uninterrupted control
• Floating-Point Math: Supports complex calculations for advanced control logic
• Online Programming & Repair: Modify programs without system shutdown
• Memory Protection: Keyswitch and password-controlled access
• Real-Time Clock: Maintains time-stamped data and scheduling
• Diagnostic LEDs: Provide quick status feedback for troubleshooting
• Software Configuration: No DIP switches or jumpers required
• Robust Design: Built for demanding industrial environments
