Vendor:
General Electric
GE IC697CPX928 Series 90-70 Central Processing Unit
Description
Description
The IC697CPX928 is a single-slot CPU module that provides high-speed processing for complex control tasks. It features a 96 MHz 80486DX4 microprocessor, making it suitable for demanding automation environments. This CPU is programmed using MS-DOS or Windows-based software and supports Ethernet TCP/IP and SNP port communication.
Specifications
- Processor: 96 MHz 80486DX4
-
Memory:
- 6 MB battery-backed RAM
- 256 KB non-volatile user flash memory
- Scan Rate: 0.4 µs per Boolean function
-
I/O Capacity:
- 12K digital I/O (any mix)
- 8K analog I/O
-
Communication Ports:
- 1 x RS232 serial port
- 2 x RS485 serial ports
- 1 x Factory Reset port
- Operating Temperature: 0°C to 50°C (can be extended to 60°C with cooling solutions)
- Power Requirements: 5V DC, 3.1A current draw.
Features
- Floating Point Support: Enables precise calculations for industrial applications.
- Battery-backed Calendar Clock: Ensures accurate timekeeping.
- Software Configuration: No DIP switches or jumpers required.
- Seven Status LEDs: Provides clear operational feedback.
- Memory Protection: Password-controlled access and hardware memory protect switch.
- Firmware Upgradability: Flash memory allows easy updates without replacing EPROMs.
